What Makes it a P9?
- Bosch Performance Line Cruise motor provides up to 65 Nm of torque and 300% support
- 1x9-speed Shimano Alivio groupset with trigger shifter
Quick Haul Highlights
- Cargo capacity: 50 kg on the rear rack, plus an additional 20 kg with optional front rack
- Fits riders 160 - 195 cm (5’3” - 6’5”), and also riders 145 - 180 cm (4’9” - 5'11") when equipped with a shorter, 350 mm seatpost
- Lots of available kid- and cargo-carrying accessories—easily create your perfect setup
- Ultra-low 490 mm standover height makes (dis)mounting and waiting at stops easier
- Shimano hydraulic disc brakes for reliable stopping power—even when heavily loaded and riding fast
- Proven safe and reliable: frame and fork are EFBE-tested up to the 150 kg (331 lb) Maximum Gross Vehicle Weight
SPECIFICATIONS
GENERAL INFO
SPEEDS: 1 x 9
WEIGHT: 22.9 kg (50.5 lb)
GEAR INCHES: 31" - 95" (2.45 - 7.57 m)
FRAME SIZES: One size
DISTANCE: SEATPOST TO HANDLEBAR: 60 - 64 cm (23.6 - 25.2 in)
DISTANCE: SADDLE TO PEDAL: 68 - 110 cm (26.8 - 43.3 in)
SUGGESTED RIDER HEIGHT: 160 - 195 cm (63 - 76.8 in)
MAX GROSS VEHICLE WEIGHT: 150 kg (330.7 lb)
MAX RIDER WEIGHT: 120 kg (264.6 lb)
FRAME
FRAME: Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg
FORK: Cargo, steel, EFBE approved: 150 kg
COCKPIT
STEM: Speedlifter, 150 mm extension, 3D Forged stem, 31.8
HEADSET: TH, cartridge bearings
HANDLEBAR: Low riser, 31.8, 6061-AL
GRIPS/BAR TAPE: Velo ergonomic, lock-on
SADDLE: Velo Comfort
SEATPOST: 31.6 mm, 6061-AL, micro-adjust clamp
SEATPOST CLAMP: Tern Collar
BRAKES
FRONT BRAKE: Shimano, hydraulic disc
REAR BRAKE: Shimano, hydraulic disc
BRAKE LEVERS: Shimano, hydraulic disc
BRAKE CABLE & HOUSING: Shimano, hydraulic disc
WHEELS
FRONT HUB: Shimano disc
REAR HUB: Shimano disc
SPOKES AND NIPPLES: Stainless steel
RIMS: Kinetix Comp, for disc
TIRES: Schwalbe Big Apple, 55-406, puncture protection, Reflex
TRANSMISSION
SHIFTER(S): Shimano Alivio, 1 x 9 spd, trigger
REAR DERAILLEUR: Shimano Alivio Shadow
CRANKSET: Tern custom, forged 6061-AL crankarm
CASSETTE/FREEWHEEL: Shimano 11-34T, 9 spd
BOTTOM BRACKET: Motor integrated
CHAIN: KMC for eBike, 9 spd
PEDALS: Urban with non-slip surface
SHIFTER CABLE & HOUSING: SP
E-SYSTEM
MOTOR: Bosch Performance, 300% Assist, 65 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
BATTERY: Bosch PowerPack 400
DISPLAY: Bosch Purion
RANGE: 400 Wh: 53 - 105 km (32.9 - 65.2 mi)
CHARGER: Compact Charger, 100-240V, 2A
BELLS & WHISTLES
BELL: Aluminum
CHAINGUARD: SKS Chainblade
KICKSTAND: Pletscher design, rear mount
LUGGAGE SOCKET: Combo Mount
FRONT LIGHT: Herrmans, 120 lumens
REAR LIGHT: Herrmans
FENDERS: Chromeplastic, stainless hardware
RACK(S): Atlas Q Rack, UpperDeck Mount System, Vertical Parking, 50 kg capacity
